Design | VA | |||
Lip material | FKM |
Shaft diameter range | |||
d1 | over | 965 | mm |
d1 | incl. | 1015 | mm |
Seal and abutment | |||
d | 910 | mm | |
b1 | 14.3 | mm | |
b | 25 | mm | |
c | 15 | mm | |
2 x | 10 | mm | |
D1 max. = d1 + 2 X |
|||
2 y | 45 | mm | |
D min. = d1 + 2 Y |
|||
B1 | 20 | mm | |
± | 4 | mm |
