G | M 80x2 | ||
d1 | 105 | mm | |
B | 32 | mm | |
d3 | 110 | mm | |
d5 | 109 | mm | |
b | 8 | mm | |
h | 3.5 | mm |
Mass | 1.05 | kg |
Associated spanner (Hook spanner in accordance with DIN 1810) | HN 16 | |||
Grub (set) / Locking screw size | M 6 | |||
Recommended tightening torque | 14.2 | N·m |
