NNU 4938 B/SPW33

Dimensions

d		190	mm
D		260	mm
B		69	mm
D₁		236	mm
F		212	mm
b		8.3	mm
K		3	mm
r_1,2	min.	2	mm
s	max.	1.1	mm

Abutment dimensions

d_a	min.	200	mm
d_a	max.	209	mm
d_b	min.	215	mm
D_a	max.	250	mm
r_a	max.	2	mm
d_n		213	mm

Calculation data

Basic dynamic load rating	C	402	kN
Basic static load rating	C₀	880	kN
Fatigue load limit	P_u	90	kN
Attainable speed for grease lubrication		2800	r/min
Attainable speed for oil-air lubrication		3200	r/min
Reference grease quantity	G_ref	85	cm³
Static radial stiffness (guideline value)		5380	N/µm

Mass

Mass bearing

Model Number: NNU 4938 B/SPW33
Inner Diameter：190mm Outer Diameter：260mm Width：69mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Super-precision bearings Cylindrical roller bearings Cylindrical roller bearings, double row, super-precision
Details： Cylindrical roller bearings, double row, super-precision
Update date：2024-12-13
Application:motor,Industrial,suction nozzle,pump accessories,plant determination,dynamic blood pressure,other processing,generator,instrument,motor,spreader series
Similar models:NNU 4938 BK/SPW33 NNU 4938 B/SPW33 NNCL 4938 CV GB 4938 NNCF 4938 CV
BEARING POWER International Trading Co.,Ltd. specialize in NNU4938B/SPW33 products，there is large inventory of SKF NNU 4938 B/SPW33 Cylindrical roller bearings, double row, super-precision. We has been built up long-term cooperation with SKF company, could make a bulk order of the NNU 4938 B/SPW33 Which SKF NNU4938B/SPW33 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
