SY 55 LF

Material

Cast iron

Dimensions

d		55	mm
A		60	mm
A₁		40	mm
A₅		34	mm
B₁		49	mm
H		126	mm
H₁		63.5	mm
H₂		24	mm
J		171.5	mm
J	max.	181	mm
J	min.	162	mm
L		219	mm
N		27.5	mm
N₁		18	mm
s₁		29	mm
Values for B₁ and s₁ before the grub screw is tightened (sleeve and inner ring bore at starting position).
Threaded hole
R_G		1/4-28 UNF
R₁		4.5	mm
R_a		45	°
Grease fitting
D_N		6.5	mm
SW_N		7	mm
G_N		1/4-28 SAE-LT
Dowel pins
J₆		201	mm
J₇		21	mm
N₄		4	mm

Calculation data

Basic dynamic load rating	C	43.6	kN
Basic static load rating	C₀	29	kN
Fatigue load limit	P_u	1.25	kN
Limiting speed		3600	r/min

Mass

Mass bearing unit

3.35

Mounting information

Hexagonal key size for grub screw	N	3	mm
Recommended tightening torque for grub screw		7.4	N·m
Appropriate SKF mounting kit		626830
Recommended diameter for attachment bolts, mm	G	16	mm
Recommended diameter for attachment bolts, inch	G	0.625	in

Appertaining products

Housing			SY 511 M
Bearing			YSP 211 SB-2F

Appropriate products

End cover

ECY 211

Model Number: SY 55 LF
Inner Diameter：55mm Outer Diameter：-mm Width：-mm
Reference speed:3600 r/min Limiting speed:-
Type：Bearings, units and housings Bearing units Y-bearing units (ball bearing units) Y-bearing plummer block units
Details： Y-bearing plummer block units Y-bearing plummer block units
Update date：2024-12-13
Application:Antenna Industry,Oral Equipment,Control,plastic rolling,Seals,sheet industry,other lathe,teaching equipment,security equipment,Processing machinery,screen filter
Similar models:NK 55/35 SYJ 55 KF NNTR 55x140x70.2ZL FYC 55 TF HK 5520 SYNT 55 FTF PSMF 455535 A51 SYNT 55 LTS 313555 C PCM 556060 E
BEARING POWER International Trading Co.,Ltd. specialize in SY55LF products，there is large inventory of SKF SY 55 LF Y-bearing plummer block units. We has been built up long-term cooperation with SKF company, could make a bulk order of the SY 55 LF Which SKF SY55LF is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
