Bearings, units and housings -- Bearing units -- Y-bearing units (ball bearing units) -- Y-bearing plummer block units -- Y-bearing short base plummer block units SKF SYF 30 TF

SYF 30 TF

Housing material

Cast iron

Dimensions

d	30	mm
A	40	mm
A₁	25	mm
B	38.1	mm
H	82	mm
H₁	42.9	mm
J	76.2	mm
L	98	mm
s₁	22.2	mm
Threaded hole
R_G	1/4-28 UNF
R₁	3	mm
R_a	45	°
Grease fitting
D_N	6.5	mm
SW_N	7	mm
G_N	1/4-28 SAE-LT

Calculation data

Basic dynamic load rating	C	19.5	kN
Basic static load rating	C₀	11.2	kN
Fatigue load limit	P_u	0.475	kN
Limiting speed		6300	r/min

(with shaft tolerance h6)

Mass

Mass bearing unit

0.94

Mounting information

Housing thread for attachment bolts	G	M10
Thread length	G₁	15	mm
Hexagonal key size for grub screw	N	3	mm
Recommended tightening torque for grub screw		4	N·m

Appertaining products

Housing			SYF 506
Bearing			YAR 206-2F

Model Number: SYF 30 TF
