SILJ 100 ES

Dimensions

d		100	mm
d₂	max.	240	mm
B		70	mm
G	6H	M 64x3
C₁	max.	57	mm
h₁		240	mm
a		7	°
d_k		130	mm
d₄	≈	110	mm
l₃	min.	86	mm
l₄	max.	360	mm
l₇	min.	116	mm
N	max.	191	mm
N₁	max.	57	mm
r₁	min.	1	mm

Bolts with internal hexagon

Size bolt with internal hexagon			M 24
Tightening torque bolt with internal hexagon			530	N·m

Calculation data

Basic dynamic load rating	C	610	kN
Basic static load rating	C₀	780	kN
Specific dynamic load factor	K	100	N/mm²
Material constant	K_M	330

Mass

Mass rod end

29.5

Model Number: SILJ 100 ES
Inner Diameter：100mm Outer Diameter：-mm Width：70mm
Reference speed:- Limiting speed:-
Type：Bearings, units and housings Plain bearings Spherical plain bearings and rod ends Rod ends with a female thread
Details： Rod ends with a female thread
Update date：2024-12-25
Application:Microwave Equipment,sheet industry,packing equipment,PVC,pressure control valve,motor,Spectrum Products,spectrometer,Other Measurements,food packaging,non-motor vehicle Electric car
Similar models:NNTR 100x240x105.2ZL N 1009 KTN/SP SILQG 100 ES PCMF 081005.5 E PBM 180200100 M1G1 HM 31/1000 BTM 100 BTN9/P4CDB SYNT 100 LW YARAG 205-100 294/1000 EF
BEARING POWER International Trading Co.,Ltd. specialize in SILJ100ES products，there is large inventory of SKF SILJ 100 ES Rod ends with a female thread. We has been built up long-term cooperation with SKF company, could make a bulk order of the SILJ 100 ES Which SKF SILJ100ES is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express. Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
